Impressed Current Cathode Protector System Of Hull/Iccp
Basic Principle
Auxiliary anode insulating with the steel plate should be installed at the hull underwater part; at the same time reference electrode should be installed in the hull. When the output current form the potential via auxiliary anode get to the hull surface, the electrode potential of hull plate surface will reach to +0.25~+0.05V(relative to Zn reference electrode).the hull plate will be protected.
Features：
The bull can be completely protected
Long service lift can be continuously used for 15-20 years
Adjust the protection current automatically and the hull can be under the state of complete
protection
Protect the screw propeller
Without affecting the speed
Continue to protect the hull in the fresh water
The device composition and the anode specification
Components: Potentiostat, Reference electrode, Auxiliary anode, Rudder grounding devices, Propeller shaft grounding device (optional)
